The CORMAK S200RHA model is an advanced automatic metal bandsaw designed for efficient serial cutting of tubes, profiles and solid materials with various geometries. A precise, compact and fully automated industrial machine, ideal for serial production, tool workshops and metalworking facilities that demand repeatability, accuracy and reliability.
The CORMAK S200RHA model is an advanced automatic metal bandsaw designed for efficient serial cutting of tubes, profiles and solid materials of different shapes. It is a precise, compact and fully automated industrial machine, perfect for serial production, tool workshops and metalworking facilities requiring repeatability, accuracy and reliability.
The CORMAK S200RHA metal bandsaw is built on a rigid cast-iron and welded frame, ensuring high stability and vibration reduction. The integrated hydraulic unit, fast feed system and adjustable arm descent mechanism with a throttle valve ensure safe and optimal operation. The cutting blade is guided by precision carbide and roller guides.
High-quality components and inverter technology allow achieving the ideal cutting speed for different materials. Hydraulic blade tensioning and precise guide adjustment extend blade life and maintain dimensional repeatability of workpieces.
This machine is recommended for workshops and production facilities engaged in serial manufacturing of steel, aluminium and non-ferrous components. It is ideal as a bandsaw for cutting pipes and profiles in steel structure fabrication, prefabrication and precision production industries.
| Type | automatic |
| Arm lifting and lowering | hydraulic, steplessly adjustable |
| Blade speed | 0–90 m/min (inverter) |
| Angle cutting | automatic 0°–45°, manual –30° to +60° |
| Vice | hydraulic |
| Minimum cutting diameter | 5 mm |
| Minimum clamping length | 30 mm |
| Vice base height | 780 mm |
| Blade dimensions | 27 × 0.9 × 2910 mm |
| Total power | 4.1 kW |
| Machine dimensions | 2250 × 1600 × 1600 mm |
| Weight | 1100 kg |
