Fully enclosed, modern fibre laser cutter for sheet metal cutting. The enclosure with protective glass provides complete protection against laser beam reflection, ensuring the safety of the operator and others in the workspace. Available with power options ranging from 1000W to 12000W. Top-quality components guarantee long-lasting and reliable operation of the fibre laser cutter.
Fibre laser cutting machines are modern devices offering numerous advantages. They are not only an excellent and far more economical alternative to CO2 technology but also come with many benefits that allow production to grow (up to 70%) and improve its quality. FIBER technology enables cutting of sheets and other materials of various thicknesses — from very thin to very thick. The wavelength in a FIBER laser is 1.064 micrometres, providing an intensity 100 times greater than that of CO2 machines of similar power.
The gantry structure is made of aged aerospace aluminium formed under 4,300-ton pressure, achieving exceptional rigidity. Aerospace aluminium offers numerous advantages: high stiffness (greater than cast iron), light weight, corrosion and oxidation resistance, and excellent machinability.
The exchangeable work table consists of upper and lower platforms whose movement and replacement are controlled by the system controller. The machine can complete a full platform exchange in 15 seconds.
The bed structure features an internal honeycomb design made of multiple welded rectangular tubes. Reinforcements inside the tubes increase the bed’s strength, rigidity, and guide rail stability, effectively preventing deformation. High strength, stability, and tensile resistance ensure up to 20 years of distortion-free use.
| WORKING AREA | 1500x3000 / 2000x4000 / 2000x6000 mm |
| POWER | 1000W 2000W 3000W 4000W 6000W 8000W 12000W |
| REPEATABLE POSITIONING ACCURACY | ±0.02 mm/m |
| MAXIMUM SPEED | 120 m/min |
| MAXIMUM ACCELERATION | 1.5G |
| DIMENSIONS | 8850x2850x2310 / 10800x3350x2310 mm |
| POWER SUPPLY | 400V 50Hz |
Actual parameters may vary depending on technical conditions and materials used.
*The price quoted is for the machine itself, excluding optional/additional equipment, installation, transport and training— please contact our consultant for more details.
▶
▶
▶
▶
▶
▶
▶
▶
▶
