Wood Dust and Chip Extractor CORMAK FM350 with Fine Dust Filters

CORMAK FM350 with fine dust filters is designed for intensive use in professional woodworking and furniture production facilities. Combining high suction power, solid steel construction and an advanced multi-stage filtration system, it effectively removes chips, sawdust and fine dust from multiple workstations simultaneously, ensuring cleaner air and safer working conditions.

Main advantages

• Airflow 4560 m³/h – efficient extraction from up to four woodworking machines simultaneously.
• Fine dust filters – capture even the smallest airborne particles for improved air quality.
• Steel impeller – precision-balanced for quiet and vibration-free operation.
• 3.8 kW three-phase motor – ensures high performance and stable negative pressure.
• Six 200 L bags (total 600 L) – long operation between emptying cycles.
• 4 extraction ports – 1 × Ø180 mm and 4 × Ø100 mm manifold for multi-machine setups.
• Adjustable legs and reinforced frame – stability even on uneven workshop floors.

Design and technology

The CORMAK FM350 features a heavy-duty powder-coated steel frame and a dual-chamber design with three fine dust filters and three waste collection bags, each with a 200 L capacity. The quick-release steel clamp system allows tool-free replacement of filters and bags, while the 300 mm steel impeller guarantees smooth operation even under heavy workloads.

Performance and precision

Operating at 2950 rpm, the CORMAK FM350 delivers a suction capacity of 4560 m³/h with stable airflow and high vacuum pressure. The integrated fine dust filtration system significantly reduces airborne dust and prevents clogging of connected machines. Its multi-inlet manifold allows efficient centralised extraction from several workstations, ideal for medium and large-scale production.

Applications

Recommended for professional woodworking processes involving:

• Spindle moulders and routers
• Planers and thicknessers
• Band and panel saws
• Belt and drum sanders

Perfect for industrial workshops, joinery plants and production lines where fine dust control and operator safety are priorities.

Standard equipment

• 3 × fine dust filters
• 3 × 200 L waste bags
• Manifold 1 × Ø180 mm / 4 × Ø100 mm
• Adjustable support legs

Optional equipment*

• 100 mm suction hose
• Galvanised hose clamps

*The price applies to the machine only, excluding optional accessories, installation, transport and training. Please contact our consultant for more details.

Technical data

Summary

CORMAK FM350 with fine dust filters provides advanced multi-stage filtration, large capacity and industrial-grade reliability. It effectively removes dust and chips while improving workplace safety and air quality in demanding production environments.

Choose CORMAK FM350 with Fine Dust Filters – a proven solution for professional wood dust extraction and clean air in your workshop.
