Wood Dust and Chip Extractor CORMAK FM340 400V with Fine Dust Filter – Efficiency and Clean Air for Professional Workshops

CORMAK FM340 400V is a compact yet highly efficient wood dust extractor designed to remove chips, sawdust and fine dust produced during woodworking. Equipped with a high-efficiency fine dust filter, it is an ideal solution for workshops and industrial environments that prioritise operator safety and clean air.

Main features

• 2-micron fine dust filter – captures even the smallest dust particles for cleaner air.
• High airflow up to 3200 m³/h – efficient dust removal for multiple workstations.
• Durable all-metal construction – long service life in continuous use.
• 300 mm metal impeller – dynamically balanced for quiet, vibration-free operation.
• 180° rotatable suction head – flexible connection layout.
• Mobile steel base – smooth and easy movement within the workspace.

Design and technology

The FM340 400V uses a 1.5 kW three-phase motor running at 2850 rpm, driving a precision-balanced metal impeller for stable suction and low noise. The fast-mounting system for filter and collection bags ensures easy maintenance. The rotatable suction head allows connection of up to three woodworking machines simultaneously.

Performance and efficiency

Thanks to optimised airflow and large inlet ports (Ø150 mm or 3 × Ø100 mm), the CORMAK FM340 effectively removes fine dust and larger wood chips without suction loss. The integrated metal fan maintains constant negative pressure, ensuring continuous extraction performance even during intensive operation.

Applications

• Panel and band saws
• Planers and thicknessers
• Spindle moulders
• Belt and wide-belt sanders

Perfect for small to medium woodworking workshops as well as industrial production lines that require effective fine dust filtration and clean working conditions.

Standard equipment

• Y-type extraction manifold (2 × Ø100 mm)
• Metal mobile base with wheels
• Plastic collection bag
• Self-cleaning fine dust filter (2-micron efficiency)

Optional equipment*

• 100 mm suction hose
• Galvanised clamp

*The price applies to the machine only, excluding optional equipment, installation, transport and training. Please contact our consultant for more details.

Technical data

Summary

CORMAK FM340 400V with a fine dust filter offers powerful suction, durable construction and effective air purification for demanding woodworking environments. It ensures cleaner air, better working comfort and extended tool life.

Invest in reliable extraction – choose the CORMAK FM340 400V with Fine Dust Filter and keep your workshop clean and safe!
