CORMAK EUROBEND series press brakes are advanced machines designed for forming and bending sheet metal, automatically adjusting during the ram cycle to achieve the required geometric profile. They are used across electromechanical, light, agricultural, shipbuilding, automotive and aerospace industries. With properly selected punches, dies and modern CORMAK CR-41 controllers, these machines ensure precision, repeatability and performance in demanding bending operations.
| Max. thickness of bent sheet (S235) | up to 4.0 mm |
| Nominal pressing force | 630 kN |
| Maximum bending length | 3200 mm |
| Throat depth | 250 mm |
| Maximum stroke of moving beam | 120 mm |
| Maximum open height | 370 mm |
| Distance between frames | 2700 mm |
| Back gauge travel | 600 mm |
| Motor power | 5.5 kW |
| Length | 3300 mm |
| Width | 1500 mm |
| Height | 1850 mm |
| Weight | 5100 kg |
The machine combines advanced technology with simple, intuitive operation, making it perfect for both precision manual work and efficient serial production. Premium components and advanced safety systems ensure durability, accuracy and user safety.
