Dual-Column Semi-Automatic Metal Bandsaw CORMAK BS1000H

Dual-Column Bandsaw CORMAK BS1000H – precision cutting of large workpieces

The BS1000H model is a high-performance dual-column metal bandsaw designed for precise cutting of large-diameter components. With its fully semi-automatic work cycle and solid construction, this machine is ideal for industrial plants involved in processing steel, cast iron, profiles and non-ferrous metals. The maximum cutting diameter reaches 1000 mm, making it the perfect solution for the most demanding cutting tasks.

Main advantages of the machine

• Fully semi-automatic cutting cycle – from clamping the material, through cutting, to the arm’s return.
• Heavy-duty dual-column construction ensuring stability and rigidity during cutting.
• Smooth cutting speed adjustment within the range of 15–80 m/min.
• Cutting blade 10000 × 67 × 1.6 mm – ideal for large cross-sections.
• Automatic shutdown in case of blade breakage.
• Blade guides with carbide inserts and bearings for precise blade tracking.

Design and technology

The solid arm made from a single cast-iron piece ensures maximum structural rigidity, translating into high cutting accuracy. The hydraulic system controls the operation of the vice and the saw arm movement – the operator only handles the material feed. In the event of a malfunction or blade breakage, the saw automatically stops operation, protecting the mechanism and increasing operator safety.

Precision and efficiency

Thanks to the use of high-quality ABB motors and durable gear transmissions, the metal bandsaw BS1000H provides long-lasting, reliable operation even under intensive use. Its performance, combined with reduced vibration levels, results in lower blade wear and perfectly perpendicular cutting edges.

Applications

The Dual-Column Bandsaw CORMAK BS1000H is used in large industrial plants, steelworks, production halls, and machining centres where precise and fast cutting of large-scale components such as pipes, profiles, steel bars, castings or structural elements is required.

Standard equipment

• Control panel with ergonomically positioned functions
• Powered blade cleaning brush
• Coolant system with a closed liquid circuit
• Bimetallic bandsaw blade – ready for operation
• CE Declaration of Conformity
• User manual

Technical data

Choose efficiency and cutting precision with the dual-column bandsaw CORMAK BS1000H – contact us to learn more!
