Product features:
UCanCam V13 Standard CAD/CAM software for CNC milling machines is a professional and versatile system used across advertising, woodworking, decoration, relief production and art design. It allows users to create complete projects from drawings to ready-to-use G-code for CNC machines and includes full machining simulation capabilities.
It also enables import of ready-made projects in vector formats: .dxf, .plt, .ai, .eps, and bitmap formats: .bmp, .jpg, .tiff, .png.
CAD Module:
- Drawing and editing tools
- Image processing (extracting contours for cutting)
- Text editing
- Function-based curve drawing
- Serial correspondence text creation
- Array along curve
- Circular / rectangular array
- Artistic transformations
- Line trimming
- Boolean operations
- Object movement
- Auto nesting
- Node editing
- Shape and position constraints
- Layer management
CAM Module:
- Profile machining
- Various tool entry strategies: ramp, gradual plunge with retraction, side entry
- Oscillating cutting
- Toolpath editing
- Trochoidal toolpath profile cutting
- Surface cleaning: raster and offset
- Trochoidal surface cleaning
- 3D engraving
- Between-lines machining
- Drilling
- Concave and convex milling
- Intelligent machining
- Prismatic machining
- Relief machining
- Relief creation from bitmap
- Toolpath creation between two curves
- Toolpath trimming
- Artistic toolpath transformation
- Rotary axis engraving
- Machining simulation
New in version V13:
- Rewritten 2D display module for faster rendering and improved visual quality.
- Added two fonts: cadhzf.shx and bigfont.shx.
- Added spiral strategies in area clearing and intelligent machining.
- Added Flute Toolpath.
- Enhanced snap-to-feature function for text.
- Vertical text inversion via line swap.
- Improved Single Stroke functionality.
- Added customisable keyboard shortcuts.
- Added “Extract Loop” function.
- Enhanced “Curve Z-map” functionality.
- Improved “Symbol Library”.
- Added image export support.
- Enhanced “Toolpath Panel”.
- Fixed several minor bugs.
Requirements: Any computer with Windows OS.
Set includes:
- USB hardware key
- USB flash drive with software
