The semi-electric pallet stacker enables lifting loads weighing up to 1,500 kg to a height of 3,300 mm. Its solid construction ensures operational safety, while the steering transmission system to the wheels provides excellent manoeuvrability despite the high overall weight. It is ideally suited for loading and unloading high-bay racking systems as well as heavy goods vehicles.
B1533 is a robust and functional semi-electric pallet stacker designed for handling loads weighing up to 1,500 kg. With the ability to lift pallets to a height of 3,300 mm and the use of an electric lifting system, the machine performs exceptionally well in high-level storage applications. Its construction ensures reliability, stability and operational safety in both warehouse and production environments.
The B1533 stacker features a reinforced steel construction designed for intensive operation under full load. The lifting structure enables stable lifting of loads to a height of 3,300 mm while maintaining rigidity and operational safety. Polyurethane wheels ensure quiet and comfortable travel, offering high wear resistance and protection for industrial floors.
The lifting system is based on an electric drive, while travel is manual, making the unit ideal for handling goods in areas where full drive automation is not required.
The B1533 model is characterised by a lifting speed of up to 150 mm/s and a safe lowering speed. The operator can control lifting and lowering processes with high precision, accelerating logistics operations and reducing the risk of load damage.
The stacker offers a turning radius of 1,430 mm, which, combined with an overall width of 800 mm, allows smooth manoeuvring even in confined warehouse spaces. The applied technical solutions improve comfort and safety during everyday operation.
The B1533 stacker is used in:
| MAX LIFTING HEIGHT | 3,300 mm |
| LOAD CAPACITY | 1,500 kg |
| LOAD CENTRE | 500 mm |
| FORK LENGTH | 1,150 mm |
| OUTER FORK WIDTH | 550 mm |
| HEIGHT WITH FORKS LOWERED | 2,220 mm |
| HEIGHT OF RAISED LIFTING STRUCTURE | 3,850 mm |
| LOWERED FORK HEIGHT | 90 mm |
| OVERALL WIDTH | 800 mm |
| OVERALL LENGTH | 1,735 mm |
| GROUND CLEARANCE | 30 mm |
| TURNING RADIUS | 1,430 mm |
| LIFTING SPEED WITH LOAD / WITHOUT LOAD | 100/150 mm/s |
| LOWERING SPEED WITH LOAD / WITHOUT LOAD | 150/100 mm/s |
| BATTERY VOLTAGE / CAPACITY | 12V 120 Ah |
| WHEEL MATERIAL | polyurethane |
| WEIGHT | 380 kg |
If you are looking for a semi-electric pallet stacker with high load capacity and extended lifting reach, the B1533 will meet the expectations of even the most demanding users. Durability, safety and the lack of mandatory inspections are a real benefit for your facil
